The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery from Nomadic Supply Company® delivers a fully integrated, high-capacity solar power solution built for off-grid adventurers and stationary installations alike. Pairing four 200W N-Type solar panels with a 3.6kWh lithium battery and a 60A MPPT charge controller, the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery gives you everything needed to generate, store, and manage clean energy right out of the box.
Engineered with versatility at its core, the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery supports a wide range of configurations — from battery chemistry and charge controller selection to optional inverter upgrades — so you can tailor the build to your exact power demands. Whether you are outfitting an RV, a marine vessel, a remote cabin, or a work truck, the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery provides the flexibility and scalability that seasoned off-grid users require.
The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery is backed by a 25-year performance warranty on the solar panels and ships with all necessary mounting hardware, cables, connectors, fuses, and monitoring tools, eliminating the guesswork of sourcing individual components. Every element of the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery is selected to work in harmony, ensuring a reliable and environmentally responsible power supply wherever your journey takes you.
Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery Features:
- Solar Power Customized Kit: The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery is a purpose-built, customized solar power kit that combines panels, a charge controller, a lithium battery, cables, connectors, mounts, and fuses into one cohesive package designed for straightforward installation and dependable performance.
- More Energy, Even in Partially Shaded Areas: The four 200W 16BB N-Type 24V rigid solar panels are designed to harvest more energy even when portions of the array are partially shaded, making the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery well-suited for real-world installation environments where full, unobstructed sunlight is not always guaranteed.
- Consistent, Environmentally-Friendly Power Supply: By harnessing solar energy and storing it in a lithium iron phosphate battery, the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery provides a consistent, environmentally friendly power supply without reliance on fossil fuels or grid power.
- Multiple Options and Free Combination: The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery offers multiple configurable options, including a choice between two MPPT charge controllers, two lithium battery models, and an optional pure sine wave inverter or inverter-charger, allowing users to freely combine components to match their specific energy storage and management needs.
- 25-Year Performance Warranty: The solar panels included in the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery are covered by a 25-year performance warranty, providing long-term assurance of panel output and reliability.
- Four 200W 16BB N-Type 24V Rigid Solar Panels for Up to 800W of Solar Input: The kit includes four 200W 16BB N-Type 24V rigid solar panels that together deliver up to 800W of total solar input power, providing a robust and efficient charging source for the 3.6kWh lithium battery bank.
- Rover 60A MPPT Charge Controller with LCD & BT2 Module or REGO 60A MPPT with Built-In Bluetooth: Buyers may choose between the Rover 60A MPPT charge controller, which features an LCD display and includes the BT2 Bluetooth module, or the REGO 60A MPPT charge controller, which integrates Bluetooth connectivity directly into the unit for wireless monitoring without an additional accessory.
- Battery Options — 3.6kWh Pro Lithium Battery (Bluetooth & Self-Heating) or 3.6kWh Core Mini Lithium Battery (Self-Heating): The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery is available with either the 3.6kWh Pro Lithium Battery, which offers Bluetooth monitoring and a self-heating function, or the 3.6kWh Core Mini Lithium Battery, which provides the self-heating function in a compact form factor.
- Optional 3000W 12V Pure Sine Wave Inverter or REGO 3000W 12V Pure Sine Wave Inverter Charger with LCD Display: An optional 3000W 12V pure sine wave inverter, or alternatively the REGO 3000W 12V pure sine wave inverter-charger with an integrated LCD display, can be added to the Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery to enable the powering of AC devices from the stored battery energy.
- Pro Lithium Battery — 5000 Cycle Life at 80% DOD, IP67 Rated, Bluetooth Monitoring, Self-Heating Function: The Pro Lithium Battery option achieves a 5,000-cycle life at 80% depth of discharge, carries an IP67 ingress protection rating for dust-tight and water-submersion resistance, supports Bluetooth monitoring for real-time battery status, and includes a self-heating function to maintain charging capability in cold-weather conditions.
- Core Mini Lithium Battery — 5000 Cycle Life at 80% DOD, IP65 Rated, Self-Heating Function: The Core Mini Lithium Battery option also delivers a 5,000-cycle life at 80% depth of discharge, is rated IP65 for dust-tight and splash-resistant protection, and includes a self-heating function to support operation in low-temperature environments.
- Rover 60A MPPT Supports 12V/24V/36V/48V Auto Recognition, Max PV Input Voltage 150VDC: The Rover 60A MPPT charge controller automatically recognizes 12V, 24V, 36V, and 48V battery systems and accepts a maximum PV input voltage of 150VDC at 25°C (140VDC at -25°C), making it adaptable to a broad range of solar array configurations.
- REGO 60A MPPT — 800W Max PV Input, MPPT Voltage Range 15–100VDC, Built-In Bluetooth: The REGO 60A MPPT charge controller handles up to 800W of maximum PV input power, operates within an MPPT voltage range of 15–100VDC for a 12V system, and features built-in Bluetooth for convenient wireless monitoring without requiring a separate module.
- Complete Kit Includes Cables, Y Branch Connectors, Z-Bracket Mounts, Fuses, and Monitoring Tools: The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery ships as a complete assembly that includes all necessary wiring cables, solar Y branch connectors, Z-bracket panel mounts, fuse holders, ANL fuse sets, and monitoring accessories required for a full installation.
- Suitable for RV, Marine, Camping, Outdoor, Cabin, and Truck Applications: The Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery is designed for use across a broad range of off-grid and mobile applications, including RVs, marine vessels, camping setups, outdoor installations, remote cabins, and work trucks.
Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery Includes:
- 4× 200 Watt 16BB N-Type 24V Solar Panel
- 1× Rover 60A MPPT with LCD (or REGO 60A MPPT with Built-In Bluetooth, depending on variant)
- 4× 2-Set Solar Panel Mounting Z Bracket
- 1× Solar Y Branch Connectors MMF+FFM Pair
- 1× Solar Panel to Charge Controller Adaptor Kit (Rover variant) or 2× Solar Panel Extension Cable + 1× Renogy 5FT 6AWG Anderson Adapter Cable (REGO variant)
- 1× Battery to Charge Controller Tray Cables
- 2× Holder with Fuse
- 1× 60A ANL Fuse Set with Fuse
Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery Specifications:
- 200W Solar Panel – Max Power at STC: 200W
- 200W Solar Panel – Open Circuit Voltage: 37.44V
- 200W Solar Panel – Short Circuit Current: 6.85A
- 200W Solar Panel – Optimum Operating Voltage: 31.03V
- 200W Solar Panel – Optimum Operating Current: 6.45A
- 200W Solar Panel – Operating Temperature: -40°F to 185°F / -40°C to 85°C
- 200W Solar Panel – Maximum System Voltage: 600 VDC UL
- 200W Solar Panel – Maximum Series Fuse Rating: 15A
- 200W Solar Panel – Dimensions: 1262 x 764 x 30mm / 49.7 x 30.1 x 1.2 in
- 200W Solar Panel – Weight: 10.6 kg / 23.4 lbs
- Rover 60A MPPT – Nominal Voltage: 12V/24V/36V/48V Auto Recognition (for non-lithium batteries)
- Rover 60A MPPT – Rated Charge Current: 60A
- Rover 60A MPPT – Rated Load Current: 20A
- Rover 60A MPPT – Max. PV Input Power: 800W/12V; 1600W/24V; 2400W/36V; 3200W/48V
- Rover 60A MPPT – Max. PV Input Voltage: 150 VDC (25°C); 140VDC (-25°C)
- Rover 60A MPPT – Self-Consumption: 0.7W–1.2W
- Rover 60A MPPT – Operating Temperature: -31°F to 113°F (-35°C to 45°C)
- Rover 60A MPPT – Dimensions: 285 x 205 x 102mm (11.22 x 8.07 x 4.00 in)
- Rover 60A MPPT – Weight: 7.9 lbs
- REGO 60A MPPT – Nominal System Voltage: 12V
- REGO 60A MPPT – Rated Charge Current: 60A
- REGO 60A MPPT – Max. PV Input Power: 800W
- REGO 60A MPPT – MPPT Voltage Range: 15–100 VDC / 12V
- REGO 60A MPPT – Solar Input Voltage Range (VOC): 100V
- REGO 60A MPPT – Max Input Current (Short-Circuit, Isc): 50A
- REGO 60A MPPT – Power Limiting Protection: Up to 800W/12V
- REGO 60A MPPT – Operating Temperature Range: -20°C to 60°C
- REGO 60A MPPT – Dimensions: 9.43 x 7.36 x 4.28 in / 239.4 x 187 x 108.8mm
- REGO 60A MPPT – Weight: 5.07 lbs / 2.30 kg
- 12V 100Ah Pro Lithium Battery – Battery Type: Lithium Iron Phosphate
- 12V 100Ah Pro Lithium Battery – Rated Capacity: 100Ah (0.5C, 25°C)
- 12V 100Ah Pro Lithium Battery – Voltage: 12V
- 12V 100Ah Pro Lithium Battery – Voltage Range: 10V to 14.8V
- 12V 100Ah Pro Lithium Battery – Cycle Life (0.5C, 25°C): 5,000 Cycles (80% DOD, 80% EOL)
- 12V 100Ah Pro Lithium Battery – Connection Method: Parallel (up to 8)
- 12V 100Ah Pro Lithium Battery – Protection Rating: IP67
Renogy 800W 12V Complete Solar Panel Kit w/ 3.6kWh Core Mini Lithium Battery FAQs:
Can I add more solar panels to expand this system?
Yes. The included Rover 60A charge controller supports a maximum PV input of 520W at 12V or 1,040W at 24V, with a maximum PV voltage of 100VDC and maximum PV current of 60A. Additional panels can be wired in series or parallel within these limits.
Do I need an inverter with this kit?
If you want to power 120V AC appliances (such as a TV, coffee maker, or laptop), you will need a separate inverter to convert the 12V DC battery output to 120V AC. Renogy offers a range of inverters to match different power demands.
What is the difference between an on-grid and off-grid system?
On-grid systems are connected to the utility grid and can export excess power. Off-grid systems are not connected to the grid and store generated power in batteries for use at any time. Off-grid systems continue operating normally during grid blackouts.
What inverter is compatible with this kit?
The inverter input voltage must match the battery bank voltage. Since this is a 12V system, use a 12V-input inverter. For higher loads, upgrading the system to 24V by reconfiguring the battery bank allows use of more powerful 24V inverters.
Are the charge controllers in this kit compatible with lithium batteries?
Yes. All Renogy Rover series charge controllers are compatible with lithium iron phosphate (LiFePO4) batteries. Select the correct battery type in the controller settings to ensure proper charging profiles.
